TSC Printers |
|
Industrial Barcode Printers |
4" Wide Printers |
|
MB240 Series
* 2-button 5-LED (MB240/MB340)/ 6-button 3.5" HVGA color touch LCD (MB240T/MB340T)
* Wide open angle for media handling
* 450 meter ribbon capacity
* Ribbon capacity monitor widget * Support 8" O.D. label roll
* Support up to 120mm label width
* Die-cast print mechanism for custom applications
* TSPL-EZD firmware for plug-n-play ease
* Available in 203 dpi and 300 dpi resolutions
* Tool-less platen roller exchange
Options include: peel-off kit, 5" OD internal rewinding kit, GPIO, internal Bluetooth module, slot-in 802.11 a/b/g/n wireless module kit, regular cutter ENERGY STAR® qualified |
|
MH240 Series
* "Thermal Smart Control" print technology produces clean, high quality barcodes
* Up to 356 mm (14") per sec. print speed
* Easy to operate with the new GUI design on display
* 3.5" color LCD with 6-button control for standard model or 4.3" color touch LCD panel with 6-button control for advanced model
* Small label peel off- Up to 0.5 inch length (MH240/MH340/MH640 and MH240T/MH340T/MH640T)
* Support 8" OD full roll internal rewinder (Only on MH240P/MH340P/MH640P)
* USB host interface for stand-alone applications
* Available in 203 dpi, 300 dpi and 600 dpi resolutions, firmware automatically detects printhead resolution and switches accordingly
* 600 meter ribbon supply
* microSD Flash memory expansion up to 32 GB
Options include: internal rewinding kit, peel-off kit, GPIO, internal Bluetooth module, slot-in 802.11 a/b/g/n wireless module kit, regular cutter, heavy duty guillotine cutter and care label cutter |
|
ML240 Series
* Up to 152 mm (6") per second print speed
* Intuitive 2.3" color LCD with 6-button menus (ML240P/ ML340P)
* Available in 203 dpi and 300 dpi resolutions
* 8 MB Flash and 16 MB SDRAM memory (ML240/ML340), 128 MB Flash and 64 MB SDRAM memory (ML240P/ML340P)
* 450 meter ribbon capacity
|
|
MX240P Series
* "Thermal Smart Control" print technology produces clean, high quality barcodes
* Heavy duty die-cast aluminum design
* Fast 536 Mhz processor
* 8 MB Flash and 16 MB SDRAM memory (ML240/ML340), 128 MB Flash and 64 MB SDRAM memory (ML240P / ML340P)
* 450 meter ribbon capacity
* Fast print speed - up to 18 inches per second
* 4.3" color LCD includes new UI design with 6-button menus and touch panel operation
* Precise media positioning & preprinted label identification
* 450 meter ribbon capacity
* Available in 203 dpi, 300 dpi and 600 dpi resolutions
* 512 MB Flash and 512 MB SDRAM memory
* 600 meter ribbon capacity
* TSPL-EZ firmware for plug-n-play ease
* USB host interface for stand-alone application
|
6" Wide Printers |
|
TTP-2610MT Series
* High quality die cast aluminum design
* "Thermal Smart Control" print technology produces clean, high quality barcodes
* 4.3" color LCD with 6-button menus and touch panel operation
* 203 dpi and 300 dpi models
* Ethernet, USB 2.0, USB host, serial and parallel connectivity are standard
* 256 MB SDRAM, 512 MB Flash
* SD Flash card memory expands storage to 32 GB
* Powerful 32 bit 536 MHz RISC processor
* Auto TPH resolution switch detection
* Standard industry emulations right out of the box including Eltron® and Zebra® language support
* USB host for stand-alone or data entry at print site
|
8" Wide Printers |
|
TTP-286MT Series
* 4.3" touch LCD display with 6-button menus
* Ethernet, USB 2.0, serial, parallel and USB Host*1 connectivity are standard
* Die-cast chassis, sheet metal structure with clear media view window
* Can manage label widths up to 241.3 mm (9.5") with a maximum print width up to 219.5 mm (8.64") wide at 300 dpi high resolution
* 600 meter ribbon supply
* 512 MB Flash and 256 MB SDRAM memory
* SD Flash memory expansion up to 32 GB
* Up to 6" per sec. print speed for 203 dpi, and 4" per sec. print speed for 300 dpi
* Powerful basic programming tools
* Options include: GPIO connectivity, Bluetooth module, and cutter module |
Desktop Barcode Printers |
2" Wide Printers |
|
TDP-225 Series
* High quality double-walled clamshell design
* 127 mm (5") OD media capacity
* Up to 152.4 mm (6") per second print speed
* Available in 203 dpi and 300 dpi resolutions
* Easy media loading
* Head open sensor
* microSD Flash memory expansion up to 4 GB
* Serial and USB 2.0 connectivity
* Optional front LCD display, internal Ethernet, peel-off module, cutter module and stand-alone keyboard
* ENERGY STAR® qualified
* Cerner certified |
|
TDP-324W Series
* High resolution 300 dpi printer, also available in 203 dpi resolutions
* Can use any roll of wristbands from any supplier
* Save up to 50% on cost of wristbands
* Designed to hold 6.5" OD wristbands
* Front LCD display
* High quality double-walled clamshell design
* Easy media loading
* Up to 152.4 mm (6") per second print speed
* microSD Flash memory expansion up to 4 GB
* Ethernet and USB 2.0 connectivity standard
* Optional peel-off module, cutter module and down-time keyboard interface
* Can be programmed to work without a computer attached
* Cerner Certified and works in any hospital system |
|
TTP-225 Series
* Small size – space saving design
* Uses industry standard ribbons and media
* High quality double walled clamshell design
* Easy media loading
* Head open sensor
* 8 MB SDRAM, 4 MB Flash memory
* Serial and USB 2.0 connectivity standard, Ethernet optional
* Options include LCD display, keyboard, cutter and peel
* Standard industry emulations right out of the box including Eltron® and Zebra® language support
* ENERGY STAR® qualified |
4" Wide Printers |
|
DA210-DA220 Series
* High quality double-walled clamshell design
* 6 inches per second print speed
* 64 MB SDRAM and 128 MB Flash memory (DA220/DA320)
* Easy media loading
* USB 2.0 (High speed mode)
* TSPL-EZ firmware emulates Eltron® and Zebra® languages out of the box
* Bluetooth 4.0
* 802.11 a/b/g/n (DA220/DA320)
* ENERGY STAR® qualified |
|
TC Series
* Perfect size – space saving design
* Standard memory of 128 MB Flash, 64 MB SDRAM for TC210 and TC310
* SD card reader for memory expansion up to 32 GB standard for TC210, TC310
* High quality double-walled clamshell design
* Easy ribbon loading
* Easy media loading featuring center-biased spring loaded design
* Durability and reliability
* 2.3" color TFT Display for TC210 & TC310 only
* Powerful firmware: TSPL-EZ, file manager, BASIC programming, stand-alone programming
* 2-year limited warranty |
|
TDP-247 Series
* High quality double-walled clamshell design
* 203 dpi and 300 dpi resolution models
* Up to 177.8 mm (7") per second print speed
* Easy media loading
* Label capacity up to 214 mm (8.4") OD
* SD Flash memory expansion up to 4 GB
* Head open sensor
* USB 2.0, parallel and serial connectivity standard
* Optional internal Ethernet interface, cutter, standalone keyboard and peel-and-present assembly
* ENERGY STAR® qualified
* Cerner certified |
|
TE200 Series
* 152.4 mm (6") per second print speed
* 300 meter (984") ribbon supply on a 25.4 mm (1") core (coated outside)
* 72 to 110 meter (361") ribbon supply on a 12.7 mm (0.5") core (coated outside)
* 127 mm (5") OD internal media supply, optional external media holder supports 214 mm (8.4") OD label rolls on 76.2 mm (3") core
* Print mechanism for kiosk applications
* 400 MHz 32-bit RISC processor with 16 MB SDRAM, 8 MB Flash memory for TE200/TE300, and 64 MB SDRAM, 128 MB Flash memory for TE210/TE310
* Internally scalable true type fonts
* TSPL-EZ firmware emulates TPLE and TPLZ languages out of the box
* Free Windows® drivers and label design software (available via download)
* ENERGY STAR® qualified |
|
TTP-243 Pro Series
* Dual-motor print engine
* 4 MB Flash and 8 MB SDRAM memory
* Optional SD card reader for expanding memory up to 4 GB
* Ribbon capacity up to 300 m (984 feet)
* Label capacity up to 214 mm (8.4") OD
* Serial & USB 2.0 connectivity are standard
* Optional serial & parallel ports
* Optional stand-alone keyboard display unit, and rotary cutter |
|
TTP-244CE
* Perfect size – space saving design
* Fast Processor 200 MHz
* Standard memory of 4 MB Flash, 8 MB SDRAM
* SD card reader for memory expansion up to 4 GB (advanced version)
* High quality double-walled clamshell design
* Easy ribbon loading & media loading
* Durability and reliability
* USB 2.0, serial, parallel and Ethernet interfaces are standard (advanced version)
* Powerful firmware: TSPL-EZ, file manager, BASIC programming, stand-alone programming
* 2-Year limited warranty |
|
TTP-244 Pro
* 200 MHz 32-bit RISC processor with 8 MB SDRAM, 4 MB Flash memory
* Internally scalable true type fonts
* TSPL-EZ firmware emulates Eltron® and Zebra® languages out of the box
* Dual-motor gear driven design
* 300 meter (984') ribbon supply on a 25.4 mm (1") core (coated side out)
* 110 mm (4.3") OD internal media supply, optional external roll mount supports
* 214 mm (8.4") OD label rolls on 76.2 mm (3") core
* 5 inches per second print speed
* USB 2.0 & RS-232 interfaces standard
* Free bundled labeling software and Windows drivers
* Standard 2 year limited warranty
|
|
TTP-247 Series
* Up to 177.8 mm (7") per sec. print speed
* 4 MB Flash memory and 8 MB SDRAM memory
* SD Flash memory expansion up to 4 GB
* User-friendly clamshell design
* Label gap sensor & full-range adjustable black mark sensor
* Parallel, serial & USB 2.0 interfaces
* Main board integrated with internal Ethernet (factory option)
* Label capacity up to 214 mm OD (8.4" OD)
* Ribbon capacity up to 300 m (984')
* TSPL-EZ firmware for plug-n-play ease
* Optional peel-off module, cutter module, stand-alone keyboard and scanner
|
|
TX200 Series
* Up to 203 mm (8") per sec. print speed
* 128 MB Flash memory and 128 MB SDRAM memory
* microSD Flash memory expansion up to 32 GB
* User-friendly clamshell design
* Serial, internal Ethernet, USB 2.0 & USB host interfaces standard
* 3.5" color TFT Display (Standard for TX600, Optional for TX200 & TX300)
* Label capacity up to 127 mm (5") OD
* Ribbon capacity up to 300 m (984')
* TSPL-EZ firmware for plug-n-play ease
* Optional peel-off module, cutter module, external Bluetooth module, slot-in 802.11 a/b/g/n wireless module, stand-alone keyboard
* ENERGY STAR® qualified
|
Mobile Barcode Printers |
2" Wide Printers |
|
Alpha-2R
* IP54-rated environmental case to resist the dust and water
* Plastic design construction that withstands 1.5 m (5 ft) drop, with IP54 case can be 2 m (6.5 ft)
* Wired & wireless communication interfaces: USB 2.0, RS-232, Bluetooth 4.0, Bluetooth 4.2 +MFi, NFC, and 802.11 a/b/g/n (supports either WiFi or Bluetooth)
* Wi-Fi CERTIFIED™
* High capacity 1620 mAh rechargeable Lithium Ion batteries
* Large paper capacity to reduce the frequency of changing paper roll
* High-speed processor and extensive memory for fast print speeds of up to 102 mm (4") per second
* Lasts more than 17 hours of printing receipts on a single battery charge
* Supports TSPL-EZ (EPL2 and ZPL emulations) ESC-POS, CPCL emulation
* 2-year standard warranty
|
|
TDM-20
* IP54-rated protective case to resist dust and water
* Withstands a drop test of 2.5 m (8.2 ft) with a IP54 case
* Wired & wireless communication interfaces: USB 2.0, MFi Bluetooth 5.0, Passive NFC tag, 802.11 a/b/g/n Wi-Fi with Bluetooth 4.2 (supports either MFi Bluetooth 5.0 or 802.11 a/b/g/n Wi-Fi with Bluetooth 4.2)
* High capacity 1130 mAh rechargeable Li-ion batteries
* Lasts more than 17 hours of printing receipts on a single battery charge
* Self-Diagnostic TPH Care Mechanism
* Supports TSPL-EZD (EPL2, ZPL2 and DPL emulations), ESC-POS, or CPCL emulation
|
3" Wide Printers |
|
Alpha-3R
* IP54-rated protective case to resist dust and water
* Plastic design with rubber over-mold construction that withstands 5 ft. (1.5 m) drop
* Wired & wireless communication interfaces: USB 2.0, RS-232, Bluetooth, and 802.11 a/b/g/n
* High capacity 2500 mAh rechargeable Lithium Ion batteries
* Large Paper capacity to reduce the frequency of changing paper roll
* High-speed processor and extensive memory for fast print speeds of up to 4" (102 mm) per second
* Last more than 30 hours of printing receipts on a single battery charge
* Supports TSPL-EZ (EPL2 and ZPL emulations), ESC-POS or CPCL emulation
* 2-Year Warranty
|
|
TDM-30
* IP54-rated protective case to resist dust and water
* Withstands a drop test of 2.5 m (8.2 ft) with a IP54 case
* Wired & wireless communication interfaces: USB 2.0, MFi Bluetooth 5.0, Passive NFC tag, 802.11 a/b/g/n Wi-Fi with Bluetooth 4.2 (supports either MFi Bluetooth 5.0 or 802.11 a/b/g/n Wi-Fi with Bluetooth 4.2)
* High capacity 3080 mAh rechargeable Li-ion batteries
* Lasts more than 42 hours of printing receipts on a single battery charge
* Self-Diagnostic TPH Care Mechanism
* Smart Battery with TSC Printer Management
* Supports TSPL-EZD (EPL2, ZPL2 and DPL emulations), ESC-POS, or CPCL emulation
|
4" Wide Printers |
|
Alpha-4L
* IP54-rated protective case to resist dust and water
* Plastic design with rubber over-mold construction that withstands 1.5 m (5 ft) drop and endure 1.8 m (6 ft) drop with its protective case
* Ready for EPL, ZPL, or CPCL environments, TSC Droid APP & SDK. WinCE APP & SDK, iOS SDK
* Wired & wireless communication interfaces: USB 2.0, RS-232, Bluetooth, and 802.11 a/b/g/n
* High capacity 5800 mAh rechargeable Li-ion batteries
* Large paper capacity to reduce the frequency of changing paper roll
* Linerless ready
* High-speed processor and extensive memory for fast print speeds of up to 102 mm (4") per second
* 2-Year Warranty is best in the industry
|
Print Engines & Modules |
4" Wide Print Engines & Modules |
|
MB Series
* Compact and robust design for optimal quality
* Easy operation interface for media handling and quality adjustment
* Designed for fast label throughput
|
|
MH Series
* 600 dpi resolution ideal for small fonts, barcodes, and graphics
* 600 m ribbon capacity
* Small label peel-off capability up to 0.5" length
|
|
PEX-1000 Series
* "Thermal Smart Control" print technology produces clean, high quality barcodes
* Heavy duty die-cast aluminum design
* Fast print speed - up to 18 inches per second
* Intuitive 3.5" color LCD with 6-button menus
* Available in 203 dpi, 300 dpi and 600 dpi resolutions
* 512 MB Flash and 512 MB SDRAM memory
* 600 meter ribbon capacity
* TSPL-EZD firmware for plug-n-play ease
|
|
TE Series
* Easy to set up, load, and operate
* Various ribbon and media support
* Self-diagnostic TPH care mechanism
|
Color Label Printers |
4" Wide Printers |
|
CPX4 Series
* Fast print speed - up to 11.8 inches per second
* High resolution 1200 x 1200 DPI
* Adjustable media width between 1" and up to 4.72"
* TSC Color Quality Management Program matches colors accurately
* One year warranty
* Versatile media support
* USB & Ethernet interfaces are fast and efficient
* High capacity ink cartridges
|
| |
